Square stainless steel 7 mm quick link

A solid square quick link

Use: For free-flight rescue parachute anchoring, or harness attachment (two-seater)

Self-certification with Working Load

• CU (WLL): 625 kg
• CR Rupture: 3125 Kg

  CU (WLL) = Working load

  CU (WLL) x 5 = Rupture load

  Material

  - Stainless steel 316 L - Standard X2 Cr Ni - Mo 17-12-2 (1.4404)
  - Type 18/12 molybdenum steel with very low carbon content, protects against the risk of intergranular corrosion.
  - Can be used in environments where type 18.10 steels reside, with the exception of those involving nitric acid.
  - Molybdenum content equal to 2/2.5, enabling it to be used in a wider range of environments than those in which type 18.10 steels are used, notably in the presence of sulfuric acid and chloride in marine environments.

  General aspect to be monitored

  quick link should be carefully checked at least once a year for corrosion, deformation and wear, as well as for operation. Any quick link that has been used to stop a violent fall must be replaced. Proceed in the same way in the event of uncertainty after checking the quick link.


  - Close by screwing on the nut to guarantee optimum safety and/or close with a wrench to the recommended tightening torque, the quick link becomes a permanent connector.Caution: no thread should be visible.
  - Payload engraved on each quick link.
  - All quick link must be inspected regularly. In case of doubt, it is the user's responsibility to replace it.
